Applications

  • Potable Water Storage
  • Wastewater Treatment Plants
  • Process Tanks for Bio Storage
  • Bulk Material Storage
  • Liquid Chemical Storage
  • And Much More

Glass-Fused Steel Tank

Fusing glass to steel is rapidly becoming the premier technology in the tank industry today. This process which involves heating the steel to over 1500 degrees and then applying a coating of silica glass creating an enamel surface that never needs to be painted and is ideal for the storage of drinking water, bulk materials, wastewater or even Biosolids storage. These tanks are commonly referred to as GFS Tanks, Glass Fused To Steel Tanks, Enamel Tanks or Glass Fused Bolted Steel Tanks.

Glass-fused-to-steel creates an impermeable barrier ideal for the storage of many and varied materials since it is not impacted by liquids or vapors, controls undercutting that can be caused by corrosion and because of its durability resistant to impact and abrasion resistance. It is also a unique deterrent to most common graffiti since it can be easily removed and it never needs painting. Your glass fused tank will look amazing for years to come.

Glass-Fused Steel Tank Benefits

  • The Glass-Fused (Enamel) tank has a longer life expectancy
  • Perfectly suited for both hot and cold climates that experience weather extremes
  • Holds color so requires no painting or re-coating
  • Ideal for Industrial applications and Wastewater
  • Use as process tanks for Biosolids storage
  • Ideal for bulk material storage (grain, limestone, cement, fly ash, wood waste, granulated
    plastics, salt) and possible fodder
  • Multiple liquid storing applications (dung water, salt brine, process, and firewater, lime milk,
    liquid fertilizers), stormwater retention or re-use.
  • Multiple potable water storage applications

Additional Tank Styles in This Size

We also carry the following tanks in this size:

  • Galvanized Steel
  • Stainless Steel
  • Thermoset Powder Coating

97,000 Gallon Glass-Fused Bolted Steel Tank

  • Never Needs Painting or Refinishing
  • Potable Water Rates NSF61
  • Ideal For Both Hot & Cold Climates
  • 1-10 Year Warranties Determined by Application & Location

97,000 Gallon Glass-Fused Bolted Steel Tank, 26′ Diameter, 24′ Eve Ht.

Description

97,000 Gallon Glass-Fused Bolted Steel Tank measuring 26-ft in diameter and 24-ft at the peak, fabricated with glass-fused steel panels bolted together using mastic and gaskets to ensure a watertight seal. The glass-fused-to-steel process ensures that water never touches the metal panels. Glass Fused Steel (GFS) tanks are a great example of the innovation occurring in the tank industry today.

Capacity97,000 Gallons
Diameter26 feet
Peak Height24 feet
MaterialGlass-Fused-To-Steel
Roof StyleGeodesic Dome, Conical, Flat, Low Profile
ColorStandard Color Options – See Specs
AccessoriesLadders (external or internal), Platforms, Stairways, Manholes (BulkHeads), Hoppers, Thermal Insulation, More
Floor OptionsSteel Floor, Embedded Ring
Design StandardAWWA – ANSI – EU Requirements
ManufactureNational Storage Tank and Affiliates
CertificationsMeets AWWA D103, ANSI, EU Codes & Requirements
Warranty1-10 Year Warranties Determined by Application & Location, Extended warranties available
Detailed SpecificationsGlass-Fused Tank Specs

Additional Information

Additional information

Dimensions24 in
Certification

ANSI, AWWA D103, EU

Diameter

26-feet

Height (FT)

24 feet

Roof Style

4 Options

Size

97000

SKU 97000GFS Category
