Water Storage Tanks and More for Wineries, Food Production, Fire Prevention, Agriculture and Chemical Industries
Bolted Steel Tanks have been the workhorse in the tank storage industry for many years. These tanks are fabricated with powder-coated steel panels bolted together with custom rubber gaskets separating each panel, making them water-tight. These tanks are commonly referred to as Carbon Bolted Steel Tanks or factory Coated Bolted Steel Tanks and are ideally suited for storage increments of over 150,000 gallons and up to 5,000,000 gallons. Depending upon the interior coating, they can be used to store petroleum products, water, wastewater, chemicals, and much more. Each tank is engineered to your site’s specifications and installed by a factory-trained crew. They are AWWA D103 and NFPA 22 standards, with a variety of roof styles, colors, and options make them the perfect solution for many commercial, industrial, and municipal water projects
Bolted Steel Tanks are the ideal solution for numerous commercial, industrial as well as municipal applications. With the correct finishes, liners, and materials they are appropriate for:
Bolted Steel Tanks have been the workhorse in the tank storage industry for many years. These tanks are fabricated with powder-coated steel panels bolted together with custom rubber gaskets separating each panel, making them water-tight. These tanks are commonly referred to as Carbon Bolted Steel Tanks or factory Coated Bolted Steel Tanks and are ideally suited for storage increments of over 150,000 gallons and up to 5,000,000 gallons. Depending upon the interior coating, they can be used to store petroleum products, water, wastewater, chemicals, and much more. Each tank is engineered to your site’s specifications and installed by a factory-trained crew. They are AWWA D103 and NFPA 22 standards, with a variety of roof styles, colors, and options make them the perfect solution for many commercial, industrial, and municipal water projects
Bolted Steel Tanks are the ideal solution for numerous commercial, industrial as well as municipal applications. With the correct finishes, liners, and materials they are appropriate for:
| Quote | Capacity | Diameter | Height | Product Number | Liner Avail | Roof Style | Certification |
|---|---|---|---|---|---|---|---|
| 4,000 | 9-ft | 8-ft | GCBST | Yes | 4 Options | AWWA D103, NFPA22 | |
| 7,000 | 12-ft | 8-ft | 461 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 8,000 | 9-ft | 16-ft | 463 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 11,000 | 15-ft | 8-ft | 465 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 12,000 | 9-ft | 24-ft | 467 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 14,000 | 12-ft | 16-ft | 469 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 16,000 | 18-ft | 8-ft | 471 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 16,000 | 9-ft | 32-ft | 473 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 20,000 | 9-ft | 40-ft | 475 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 21,000 | 12-ft | 24-ft | 477 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 22,000 | 21-ft | 8-ft | 479 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 22,000 | 15-ft | 16-ft | 481 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 24,000 | 9-ft | 48-ft | 483 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 28,000 | 9-ft | 56-ft | 485 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 29,000 | 12-ft | 32-ft | 487 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 32,000 | 26-ft | 8-ft | 489 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 32,000 | 18-ft | 16-ft | 492 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 34,000 | 15-ft | 24-ft | 494 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 36,000 | 9-ft | 72-ft | 496 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 40,000 | 9-ft | 80-ft | 499 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 42,000 | 30-ft | 8-ft | 501 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 43,000 | 12-ft | 48-ft | 503 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 44,000 | 21-ft | 16-ft | 505 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 45,000 | 15-ft | 32-ft | 507 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 48,000 | 18-ft | 24-ft | 509 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 50,000 | 33-ft | 8-ft | 511 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 50,000 | 12-ft | 56-ft | 513 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 56,600 | 15-ft | 40-ft | 515 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 57,000 | 12-ft | 64-ft | 517 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 64,000 | 18-ft | 32-ft | 519 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 64,000 | 12-ft | 72-ft | 521 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 65,000 | 26-ft | 16-ft | 523 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 66,000 | 21-ft | 24-ft | 525 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 67,000 | 15-ft | 48-ft | 527 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 71,000 | 39-ft | 8-ft | 529 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 71,000 | 12-ft | 80-ft | 531 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 78,000 | 15-ft | 56-ft | 533 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 80,000 | 18-ft | 40-ft | 535 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 82,000 | 42-ft | 8-ft | 537 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 83,000 | 30-ft | 16-ft | 539 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 88,000 | 21-ft | 32-ft | 541 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 89,000 | 15-ft | 64-ft | 543 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 96,000 | 18-ft | 48-ft | 545 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 97,000 | 26-ft | 24-ft | 547 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 100,000 | 15-ft | 72-ft | 549 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 101,300 | 65-ft | 40-ft | 552 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 106,000 | 48-ft | 8-ft | 554 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 110,000 | 21-ft | 40-ft | 556 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 112,000 | 15-ft | 80-ft | 558 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 113,000 | 18-ft | 56-ft | 560 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 125,000 | 30-ft | 24-ft | 562 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 129,000 | 18-ft | 64-ft | 564 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 132,000 | 21-ft | 48-ft | 567 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 141,000 | 39-ft | 16-ft | 569 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 143,000 | 55-ft | 8-ft | 571 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 145,000 | 18-ft | 72-ft | 573 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 150,000 | 33-ft | 24-ft | 575 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 153,000 | 21-ft | 56-ft | 577 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 161,000 | 18-ft | 80-ft | 579 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 162,000 | 26-ft | 40-ft | 581 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 163,000 | 42-ft | 16-ft | 583 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 166,800 | 60-ft | 8-ft | 585 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 167,000 | 30-ft | 32-ft | 587 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 175,000 | 21-ft | 64-ft | 589 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 194,000 | 26-ft | 48-ft | 591 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 197,000 | 21-ft | 72-ft | 593 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 200,000 | 33-ft | 32-ft | 595 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 202,000 | 65-ft | 8-ft | 597 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 209,000 | 30-ft | 40-ft | 599 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 212,000 | 39-ft | 24-ft | 601 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 219,000 | 21-ft | 80-ft | 604 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 235,000 | 26-ft | 56-ft | 606 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 246,000 | 42-ft | 24-ft | 612 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 250,000 | 30-ft | 48-ft | 608 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 268,000 | 26-ft | 64-ft | 610 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 282,000 | 39-ft | 32-ft | 615 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 292,000 | 30-ft | 56-ft | 617 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 300,000 | 33-ft | 48-ft | 619 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 304,000 | 80-ft | 8-ft | 621 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 318,000 | 48-ft | 24-ft | 623 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 328,000 | 42-ft | 32-ft | 625 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 333,600 | 60-ft | 16-ft | 627 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 334,000 | 30-ft | 64-ft | 629 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 353,000 | 39-ft | 40-ft | 631 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 375,000 | 30-ft | 72-ft | 633 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 401,000 | 92-ft | 8-ft | 635 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 404,000 | 65-ft | 16-ft | 637 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 410,000 | 42-ft | 40-ft | 639 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 423,000 | 29-ft | 48-ft | 641 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 424,000 | 48-ft | 32-ft | 643 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 428,000 | 55-ft | 24-ft | 645 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 500,400 | 60-ft | 24-ft | 647 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 530,000 | 48-ft | 40-ft | 649 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 571,000 | 55-ft | 32-ft | 651 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 606,000 | 65-ft | 24-ft | 653 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 608,000 | 80-ft | 16-ft | 655 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 667,400 | 60-ft | 32-ft | 657 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 754,700 | 72-ft | 24-ft | 659 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 802,000 | 92-ft | 16-ft | 661 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 807,000 | 65-ft | 32-ft | 663 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 912,000 | 80-ft | 24-ft | 665 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 1,203,000 | 92-ft | 24-ft | 669 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 2,400,000 | 125-ft | 26-ft | 671 | Yes | 4 Options | AWWA D103, NFPA22 | |
| 2,868,000 | 145-ft | 25-ft | 673 | Yes | 4 Options | AWWA D103, NFPA22 |
